Bale Breaker BRT HARTNER BB
Efficient Breaking and Unraveling of Press Bales
The Bale Breaker BRT HARTNER BB serves for breaking open compressed bales of PET-bottles, waste paper, residual waste, plastic waste and many other recyclables.
The integrated standard moving floor conveyor allows for an even material stream to the bale breaking unit, which consist of a drum and a dynamic down holding device.
Technical Data
| Working Data | BB |
| Working width | 1,780 mm |
| Number of push-boards | 12 pieces |
| Feeding height | approx. 800 mm |
| Total height | 2,500 mm |
| Hopper length min. | 6,000 mm |
| Total length min. | 8,400 mm |
| Extension in steps of | 1,500 mm |
| Hopper length max. | 12,000 mm |
| Total length max. | 14,400 mm |
| Bale dimensions max. (w x h x l) | 1,200 x 1,200 x 2,500 mm |
| Bale weight | approx. 300 – 1,500 kg |
| Power requirement Moving Floor | 4 to 22 KW |
| Power requirement | 7,5 to 11 KW |
| Weight | 11,5 t |
| Throughput | up to 10 t/h |
| *Throughput can vary depending on the material, material properties, moisture and composition. All values are approximate. | |
